Mini Series・Mini Quick Paper

Features

  • Screw type disc enables quick change by hand without tools.
  • Best suited for surface grinding and curve grinding!
  • Small diameter wheel is designed to fit in the narrow space or small area.

Applications

This product should be used with a MiniQuickPAD (which is sold separately).
  • Grain type A: Light grinding, polishing and weld bead removal of steel, stainless steel. Finishing spot welding, rough finishing, cleaning, flaw grinding
  • Grain type Z: Light grinding, polishing and weld bead removal of steel, stainless steel. Grinding application includes finishing spot welding.

mounting the disc method

Specifications

Diameter
(mm)
Grain Grit Packing
Outer Box
(pcs×inner box)
Maximum
operation
speed
50 A 40・60・80・120・180・240・320・400 50pcs
(5pcsx10boxes)
63m/s
(3,800m/min)
24,070rpm
Z 36・60・80・120
75 A 40・60・80・120・180・240・320・400 50pcs
(5pcsx10boxes)
63m/s
(3,800m/min)
16,050rpm
Z 36・60・80・120

Product Code

◆The unit of diameter, thickness and bore is the mm.
◆Each product lines are available in different sizes, please contact us.

Article


Working surface
(Grain type A)

Diameter 50mm
Working surface
(Grain type Z)

Diameter 75mm(3inch)
Working surface
(Grain type Z)

Package
