Mini Series・Mini Quick FC

Features

  • Screw type disc enables quick change by hand without tools.
  • Coating cushioned fiber with abrasive grain to provide moderate stock removal and smooth surface.
  • Its breathability eliminates the clogging and heat damage problem.
  • Small diameter wheel is designed to fit in the narrow space or small area.

Applications

This product should be used with a MiniQuickPAD (which is sold separately).
  • Ideal for surface grinding, cleaning, flaw grinding, paint stripping and rust removal of wide range of work pieces such as non ferrous metal (steel, stainless steel, aluminum) and plastic (FRP).

mounting the disc method

Specifications

Diameter
(mm)
Grit Packing
Outer Box
(pcs×inner box)
Maximum
operation
speed
50 Coarse・Medium・Fine・Super fine 50pcs
(5pcsx10boxes)
63m/s
(3,800m/min)
24,070rpm
75 Coarse・Medium・Fine・Super fine 50pcs
(5pcsx10boxes)
63m/s
(3,800m/min)
16,050rpm

Coarse…Comparable to #120 Medium…Comparable to #240 Fine…Comparable to #320
Super fine…Comparable to #600
Product Code

◆The unit of diameter, thickness and bore is the mm.
◆Each product lines are available in different sizes, please contact us.

Article


Working surface(Coarse)

Working surface(Medium)

Working surface(Fine)

Working surface()

Package
